Filettatura | ||||||
---|---|---|---|---|---|---|
Codice | h2 | D | h1 | Metrica | GAS/BSP | UNF/JIC |
SF1/8 | 6 | 9.8 | 4 | M10 | 1/8" | 7/16" |
SF1/4 | 7 | 13.1 | 5 | 1/2" | M13,M14 | 1/4" |
SF3/8 | 7 | 16.5 | 5 | M16 | 3/8" | 5/8" |
SF1/2/M18 | 9 | 18.3 | 7 | M18 | 1/2" | 3/4" |
SF1/2/M20 | 9 | 21.3 | 7 | M20 | 1/2" | - |
SF5/8 | 9 | 22.4 | 7 | M22 | 5/8" | 7/8" |
SFM24 | 9 | 23,5 | 7 | M24 | - | - |
SF3/4 | 9 | 25.5 | 7 | 1.1/16" | M26 | 3/4" |
SF7/8 | 9 | 27.9 | 7 | M28 | 7/8" | 1.1/8" |
SF1 | 9 | 32 | 7 | M32 | 1" | 1.5/16" |
SF1.1/8 | 9 | 35.7 | 7 | M36 | 1.1/8" | 1.1/2", 1.3/8" |
SF1.1/4 | 9 | 41.5 | 7 | 1.5/8" | M42 | 1.1/4" |
